1.1.8 BO-FLEX CY BLACK 0,6/1KV

Back
1. 1. Flexible Control and Power cables Cables
and wires
POWER AND CONTROL CABLES
TEMPARATURE RANGE
WORKING VOLTAGE
TEST VOLTAGE
UV RESISTANCE
power and control cable, various applications, PVC, conductor class 5, number coded black cores, screened, outdoor
Info request Download PDF

Technical data and Product features

Show Hide
TEMPERATURE RANGE
Occasional flexing: -5°C to +70°C
Fixed installation: -40°C to +80°C
NOMINAL VOLTAGE
U0/U: 600/1000 V
TEST VOLTAGE
4000V
MINIMUM BENDING RADIUS
Static/Occ. moved: 6/20xOD*
PRODUCT FEATURES
Flame-retardant according IEC 60332-1-2
UV and weather-resistant according to ISO 4892-2
Ozone-resistant according to EN 50396
High degree of screening low transfer impedance (max. 250 Ω/km at 30 MHz)

Applications

Flexible control and power cables are designed for fixed installation and applications involving occasional movement. They provide reliable power supply, control and signal transmission in industrial machinery, equipment and automation systems.
